12kWh Single Phase SRNE Solar System with 33.4kWh SRNE Lithium Battery

System Overview

The 12kWh SRNE Single Phase Solar System is a high-capacity hybrid solar power solution designed for homes, offices, businesses, farms, shops, institutions and other applications requiring reliable single-phase electricity with substantial battery backup.

The system combines a 12kW/12kWh SRNE 48V hybrid solar inverter, a 33.4kWh total SRNE lithium battery bank, and 22 high-efficiency 635W Jinko bifacial monocrystalline solar panels.

The solar array has a total installed capacity of:

22 × 635W = 13,970W

Total Solar PV Capacity: 13.97kWp

The battery storage consists of:

2 × 16.7kWh SRNE Lithium Batteries = 33.4kWh total storage

This configuration provides substantial daytime solar generation while giving the system a large energy reserve for evening, nighttime and backup operation.

---

1. SRNE 12kWh/12kW Single Phase Hybrid Solar Inverter

Model: HESP48120S200-H

The SRNE HESP48120S200-H is the central energy-management component of the system. It manages power generated by the solar panels, battery storage and available grid supply, while supplying power to the connected single-phase loads.

Specifications

• Brand: SRNE
• Model: HESP48120S200-H
• System: Single Phase
• Rated Output Power: 12,000W
• Maximum Output Power: 24,000VA peak
• Rated Output Current: 52.2A
• Maximum Output Current: 54.4A
• Battery System: 48V
• MPPT Trackers: 2
• Type: Hybrid Solar Storage Inverter
• Application: Residential, commercial and small industrial solar systems

The inverter’s 12,000W rated output provides substantial capacity for running multiple household or commercial loads simultaneously, while its higher peak capability assists with loads that require additional starting power.

Advantages of the SRNE 12kW Hybrid Inverter

• High 12kW continuous power output
• 48V battery compatibility
• Hybrid operation with solar, battery and grid power
• Two MPPT trackers for flexible PV configuration
• High peak output capability for demanding loads
• Suitable for single-phase residential and commercial applications
• Allows stored solar energy to be used when solar generation is unavailable
• Helps reduce dependence on grid electricity

---

2. 33.4kWh SRNE Lithium Battery Bank

The system has been upgraded to include:

2 × 16.7kWh SRNE Lithium Batteries

Total Battery Storage Capacity: 33.4kWh

The lithium batteries provide energy storage for the solar system. During periods of strong solar generation, available solar energy can be used to charge the batteries. The stored energy can then be used during the evening, at night or during grid interruptions.

The supplied battery information identifies the SRNE EOS low-voltage battery as a 51.2V LFP battery, with 314Ah capacity, approximately 16.07kWh battery energy, an 8,000-cycle lifespan, and support for up to 16 units in parallel.

Battery Specifications

• Brand: SRNE
• Battery Type: Lithium Iron Phosphate (LFP)
• Nominal Voltage: 51.2V
• Capacity: Approximately 16.7kWh per battery as requested
• Quantity: 2 batteries
• Total System Storage: 33.4kWh
• Cycle Life: Up to 8,000 cycles based on the supplied SRNE battery information
• Maximum Parallel Capability: Up to 16 units
• Mounting: Floor or wall mounting supported
• Protection: IP65 rating stated for the supplied EOS battery information
• Communication: Compatible with supported inverter communication protocols
• Monitoring: Wi-Fi and Bluetooth functionality stated for the supplied battery information

The battery is designed as a modular energy-storage solution and can be expanded in systems where additional compatible batteries are required.

---

3. 635W Jinko Bifacial Monocrystalline Solar Panels

The system has been adjusted to:

22 × 635W Jinko Bifacial Monocrystalline PV Modules

Total PV capacity:

22 × 635W = 13,970W

Total Solar Capacity: 13.97kWp

The supplied specifications identify the Jinko panels as:

• 635W per panel
• Bifacial monocrystalline technology
• 24% transfer efficiency
• N-type monocrystalline technology
• TOPCon technology
• Bifacial design
• 25-year warranty

Advantages

• High 635W output per panel
• High system-level solar generation
• Bifacial technology can utilize suitable reflected light from the rear side
• N-type/TOPCon technology
• High efficiency
• Suitable for residential and commercial installations
• 25-year panel warranty as specified

---

4. Solar PV Cabling

The system includes solar PV cabling for connecting the solar modules to the combiner and inverter.

Included:

• 6.0mm² Solar PV Cable – 100 meters
• 10mm² Solar PV Cable – 80 meters

The cables provide the electrical connection between the PV array, protection equipment and inverter.

---

5. Battery Cables

The system includes:

35mm² Battery Cable – 10 meters

The battery cable is used for the high-current DC connection between the lithium battery bank and the hybrid inverter.

Proper cable sizing and installation are important because the 12kW inverter can draw substantial DC current from the 48V battery system.

---

6. Automatic Changeover Switch

The system includes:

63A Double-Pole Single-Phase Automatic Changeover Switch

The automatic changeover switch facilitates switching between the available power sources according to the configured installation.

This helps provide continuity of power to supported loads when the primary supply becomes unavailable.

---

7. DC Protection

The system includes:

125A Double-Pole DC Breaker

The DC breaker provides isolation and protection for the DC side of the solar installation.

It can assist with:

• DC circuit isolation
• Overcurrent protection
• Maintenance safety
• Protection of associated equipment

---

8. Surge Protection

The system includes a:

Surge Protector

The surge protection device helps protect sensitive electrical and electronic equipment from transient voltage surges.

This is an important component in a solar installation where the PV array and associated cabling are exposed to outdoor electrical disturbances.

---

9. Digital Automatic Voltage Regulator

The system includes:

Digital Automatic Voltage Regulator

The regulator is designed to assist with voltage stabilization for the applicable electrical supply and provide additional protection for connected equipment from voltage fluctuations.

---

10. 12-Way Solar Combiner Box

The system includes:

1 × 12-Way Combiner Box

The combiner box provides a centralized point for organizing and combining appropriate solar PV strings before connection to the inverter.

It also assists with:

• PV string organization
• DC circuit isolation
• Protection
• Cable management
• Easier system maintenance

---

11. Aluminum Solar Mounting Rails

The system has been adjusted to:

9 × Long Aluminum Mounting Rails

The aluminum rails provide the mounting framework for securely installing the 22 solar panels.

Features

• Aluminum construction
• Corrosion resistant
• Lightweight
• Suitable for outdoor solar installation
• Designed for secure PV module mounting
• Long-rail design for efficient panel arrangement

The supplied specifications identify the mounting rails as standard aluminium, corrosion-resistant long rails.

---

12. Cable Management and Installation Accessories

The system also includes:

• 4 × 4 Trunking
• 25mm Flexible Conduit
• Cable ties
• Electrical tapes
• Cable lugs

These accessories assist with neat cable routing, protection and professional installation of the system.

---

How the System Works

During the Day

The 13.97kWp solar array generates electricity from sunlight.

22 × 635W Jinko Panels → SRNE Hybrid Inverter → Connected Loads

The solar energy can be used directly by the connected loads. Where solar production exceeds immediate consumption, available energy can be used to charge the lithium battery bank.

Evening and Night

When solar production decreases or stops, the system can utilize the stored energy:

33.4kWh Lithium Battery Bank → SRNE Inverter → Connected Loads

This allows stored solar energy to continue powering supported loads after sunset.

During a Grid Outage

The battery bank can provide backup energy through the hybrid inverter to supported loads, subject to the inverter’s rated capacity, battery state of charge and the specific installation configuration.

---

Major Advantages of the Complete System

1. Large 13.97kWp Solar Array

The 22 × 635W panels provide nearly 14kWp of installed solar capacity, allowing substantial daytime energy generation.

2. Large 33.4kWh Battery Storage

Two 16.7kWh lithium batteries provide a large energy reserve for evening, nighttime and backup use.

3. High 12kW Inverter Capacity

The 12kW SRNE hybrid inverter can support a substantial number of residential and commercial loads simultaneously.

4. Extended Backup Capability

The 33.4kWh battery bank provides significantly more stored energy than a single battery configuration, allowing longer backup operation depending on the connected load.

5. Efficient Solar Utilization

The system can prioritize solar energy for daytime loads while directing available surplus energy toward battery charging.

6. Bifacial Solar Technology

The Jinko bifacial modules can capture additional suitable rear-side irradiance, depending on the mounting surface and installation environment.

7. Expandable Battery Architecture

The supplied SRNE EOS battery information indicates support for up to 16 units in parallel, allowing substantial future expansion where compatible equipment and system design permit.

8. Long Battery Cycle Life

The supplied SRNE battery information specifies an 8,000-cycle lifespan, providing a long-term energy-storage solution.

9. Automatic Power Changeover

The 63A single-phase automatic changeover provides automatic switching between available power sources.

10. Comprehensive Electrical Protection

The inclusion of DC breakers, surge protection, combiner box, voltage regulation and appropriate cabling provides multiple protection and isolation points throughout the system.

11. Flexible Installation

The SRNE EOS battery information indicates both wall and floor mounting options, making the battery system adaptable to different installation environments.

12. Professional Solar Solution

The complete configuration combines the inverter, solar panels, lithium storage, mounting structure, protection equipment, cabling and installation accessories into one integrated solar power system.

---

Complete System Specification

Component	Specification
System Type	12kWh/12kW Single Phase Hybrid Solar System
Hybrid Inverter	SRNE HESP48120S200-H
Inverter Output	12,000W
Maximum Output	24,000VA
Battery System	48V low-voltage
MPPT Trackers	2
Solar Panels	22 × 635W Jinko Bifacial Monocrystalline
Total PV Capacity	13.97kWp
Lithium Batteries	2 × 16.7kWh SRNE
Total Battery Storage	33.4kWh
PV Cable	6mm² – 100m
PV Cable	10mm² – 80m
Battery Cable	35mm² – 10m
Changeover Switch	63A Double Pole Single Phase Automatic
DC Breaker	125A Double Pole
Combiner Box	12-Way
Surge Protector	1
Automatic Voltage Regulator	1 Digital
Aluminium Rails	9 Long Aluminium Rails
Trunking	4 × 4
Flexible Conduit	25mm
Accessories	Tapes, cable ties & cable lugs

Warranty & Installation

The supplied terms state that complete solar systems come with a 5-year warranty. They also state free installation countrywide and free delivery within Nairobi.

Final System Description

The 12kWh SRNE Single Phase Solar System combines a 12kW SRNE HESP48120S200-H h

ybrid inverter, 22 × 635W Jinko bifacial monocrystalline solar panels providing 13.97kWp of solar generation, and 2 × 16.7kWh SRNE lithium batteries providing 33.4kWh of total energy storage. With automatic changeover, PV protection, surge protection, voltage regulation, aluminium mounting rails and the required cabling accessories, the system is designed to provide reliable daytime solar power, substantial energy storage and backup power for residential and commercial applications.
