Description
12kWh SRNE Three-Phase Solar System with a 16.7kWh SRNE Lithium Battery
System Configuration
- 12kW SRNE Three-Phase Hybrid Solar Inverter
- 16.07kWh SRNE Lithium LFP Battery
- 16 × 635W Jinko Bifacial Monocrystalline Solar Panels
- Total PV capacity: 10.16kWp
Three-Phase Inverter
The single-phase SRNE HESP48120S200-H in the previous configuration will be replaced with a 12kW three-phase SRNE hybrid inverter.
The inverter will provide:
- 12kW rated AC output
- Three-phase power distribution
- Hybrid operation with solar, battery and grid/generator
- Solar PV charging of the battery
- Automatic backup during power interruptions
- Intelligent energy management
- Compatibility with lithium battery storage
Important: The exact model number and electrical specifications of the three-phase SRNE inverter should be confirmed before finalizing the quotation, because the original document specifies a single-phase HESP48120S200-H rather than a three-phase model.
Battery Storage
SRNE EOS 16.07kWh Lithium Battery – SR-EOS15B
- Capacity: 16.07kWh
- Voltage: 51.2V
- Capacity: 314Ah
- Battery chemistry: LFP
- Cycle life: 8,000 cycles
- Expected lifetime: 20 years
- IP65 protection
- Wi-Fi and Bluetooth monitoring
- LCD display
- Wall or floor mounting
- Up to 16 units can be connected in parallel, allowing expansion up to 256kWh.
Solar PV System
16 × 635W Jinko bifacial monocrystalline panels
- Total installed PV capacity: 10.16kWp
- N-type monocrystalline
- TOPCon technology
- Bifacial design
- 24% transfer efficiency
- 25-year warranty.
Balance of System
The remaining components can be retained from the original configuration:
- 8 × aluminum mounting rails
- 100m 6mm² solar PV cable
- 80m 10mm² solar PV cable
- 10m 35mm² battery cable
- Three-phase automatic changeover switch (replace the original 63A single-phase unit)
- 125A DC double-pole breaker
- Surge protection device
- Digital automatic voltage regulator
- 12-way combiner box
- 4×4 trucking
- 25mm flex conduit
- Cable ties, tapes and cable lugs.
Key Advantages of the Three-Phase Version
- Three-phase power distribution – suitable for homes, offices, businesses and facilities with three-phase electrical loads.
- 12kW usable inverter capacity – provides substantial power for multiple appliances and equipment operating simultaneously.
- 16.07kWh battery storage – provides energy storage for evening, nighttime and backup requirements.
- 10.16kWp solar array – provides strong daytime solar generation and battery-charging capability.
- Reduced dependence on the grid – solar energy can supply loads while excess generation charges the battery.
- Automatic backup – the system can maintain essential loads during grid interruptions when correctly configured.
- Scalable battery storage – the SRNE EOS battery platform supports parallel expansion up to 16 units.
- Bifacial solar technology – the Jinko panels can capture additional reflected light from the rear side under suitable installation conditions.
- Long-life lithium storage – the battery is specified at 8,000 cycles and a 20-year lifetime.
- Smart monitoring – Wi-Fi/Bluetooth connectivity and an LCD display allow system performance to be monitored.
Final System Description
12kW Three-Phase SRNE Hybrid Solar System with 16.07kWh SRNE Lithium Battery and 10.16kWp Jinko Bifacial Solar PV Array
This configuration is designed to provide three-phase solar power, battery energy storage and automatic backup, making it suitable for residential, commercial and small industrial applications requiring reliable three-phase electricity.
The original document specifies free installation countrywide, free delivery within Nairobi, and a 10-year warranty for complete solar systems.
📞📞CONTACT US ON:0799316769/0708549953
👷♀️FREE INSTALLATION COUNTRYWIDE👷♀️
🎁🎁10 YEARS WARRANTY🎁🎁
