55 kVA / 50 kW FELICITY HIGH-VOLTAGE THREE-PHASE SOLAR SYSTEM

System Overview

The 55 kVA / 50 kW Felicity High-Voltage Three-Phase Solar System is a powerful commercial and industrial-grade solar energy solution designed to provide reliable electricity for homes, businesses, offices, institutions, farms, workshops and other facilities with substantial energy demands.

At the heart of the system is the Felicity IVGM50KHP3G2 55 kVA / 50 kW Three-Phase On/Off-Grid Hybrid Inverter, which combines solar generation, high-voltage battery storage and grid power management in one advanced energy-management system.

The system is designed to operate both on-grid and off-grid, allowing solar energy to power loads during the day, charge the battery bank with excess solar energy and provide stored energy when solar production is insufficient or grid power is unavailable.

The package incorporates 90 pieces of 635 W Jinko monocrystalline solar panels, providing a total installed PV capacity of:

90 × 635 W = 57,150 W = 57.15 kWp

The system also includes 20 pieces of 5.12 kWh Felicity high-voltage lithium batteries, giving a total nominal battery storage capacity of:

20 × 5.12 kWh = 102.4 kWh

This provides approximately 102.4 kWh of nominal battery storage, making the system suitable for substantial nighttime energy consumption and backup requirements.

---

1. FELICITY 55 kVA / 50 kW THREE-PHASE HYBRID INVERTER

Model:

Felicity IVGM50KHP3G2

Inverter Type:

Three-Phase On/Off-Grid High-Voltage Hybrid Inverter

Protection Rating:

IP65

The Felicity IVGM50KHP3G2 is the main energy-management component of the system. It manages electricity generated by the solar panels, battery charging and discharging, grid electricity and connected loads.

With a rated output of 50 kW / 55 kVA, the inverter is capable of supplying substantial three-phase loads and is particularly suitable for commercial and industrial applications.

Key Inverter Specifications

---

2. 80 kW BUILT-IN MPPT SOLAR CHARGING CAPACITY

One of the major features of the Felicity inverter is its substantial 80 kW built-in MPPT capacity, configured as:

20 kW × 4 MPPTs

This allows the inverter to efficiently extract available energy from the solar PV array under varying sunlight conditions.

The inverter has:

• 4 MPPT channels
• 8 PV input ports
• 36 A PV input current per MPPT
• 150–850 VDC PV operating voltage range

This provides considerable flexibility when designing the PV array and allows the solar panels to be divided into multiple strings for improved energy harvesting.

---

3. 57.15 kWp JINKO MONOCRYSTALLINE SOLAR PV ARRAY

The system comes with:

90 × 635 W Jinko Monocrystalline Solar PV Modules

Total installed solar capacity:

57.15 kWp

The Jinko monocrystalline modules are designed to provide high energy generation from available roof or ground-mounted space.

The solar array supplies electricity to the Felicity hybrid inverter, which intelligently directs the generated energy to the connected loads, battery bank or grid depending on the operating conditions and programmed energy-management strategy.

Benefits of the Jinko PV Modules

• High-efficiency monocrystalline technology
• High power output per panel
• Excellent performance under strong sunlight
• Suitable for commercial and industrial installations
• Durable construction
• Long service life
• Reduced space requirement for a given installed capacity
• Excellent compatibility with modern high-voltage hybrid inverter systems

---

4. 102.4 kWh FELICITY HIGH-VOLTAGE LITHIUM BATTERY BANK

The system includes:

20 × FLH48100UMG2

Each battery:

• 48 V
• 100 Ah
• 5.12 kWh
• Grade A lithium battery

Total nominal battery storage:

20 × 5.12 kWh = 102.4 kWh

The battery bank provides substantial energy storage for nighttime operation, load shifting and backup power.

During periods of high solar production, excess solar energy can be stored in the battery bank. When solar production decreases or the grid becomes unavailable, the stored energy can be released to supply the connected loads.

Major Battery Advantages

• High energy-storage capacity
• Grade A lithium cells
• LiFePO₄ battery technology
• Long service life
• High safety and thermal stability
• Suitable for frequent charge/discharge cycles
• Reduced maintenance requirements
• High-voltage system architecture
• Suitable for commercial energy storage
• Excellent integration with the Felicity hybrid inverter

---

5. BATTERY MASTER CONTROLLER

The system includes:

1 × FLH48100UCG2 Master Battery Controller

The Master Battery Controller serves as the central control interface for the battery bank.

It facilitates communication and coordination between the battery modules and the hybrid inverter, helping the system manage:

• Battery charging
• Battery discharging
• State of charge
• Battery protection
• Battery communication
• Battery operating status
• Fault and protection information

The controller is an important part of ensuring that the multiple battery modules operate together as one coordinated energy-storage system.

---

6. TWO 13-LAYER BATTERY RACKS

The system includes:

2 × FLH48100R13G2 13-Layer Battery Racks

The 13-layer racks provide an organized and secure method of installing the battery modules.

With 20 battery modules distributed across the two racks, the installation provides:

• Organized battery arrangement
• Secure mechanical support
• Improved accessibility
• Professional equipment-room appearance
• Easier maintenance
• Efficient battery cabling
• Proper separation and arrangement of battery modules

The rack-based design is particularly suitable for commercial and industrial installations where multiple batteries are required.

---

7. 1,000 METRES OF 10 mm² SOLAR PV CABLE

The system includes:

1,000 meters of 10 mm² solar PV cable

Comprising:

• 500 meters RED
• 500 meters BLACK

The dedicated solar PV cable is used for connecting the PV modules to the inverter and associated DC protection equipment.

The appropriate cable sizing helps minimize voltage drop and provides reliable transmission of the DC power generated by the solar array.

---

8. 32 × 4.8 METRE ALUMINIUM LONG RAILS

The mounting system includes:

32 × 4.8 m Aluminum Long Rails

These rails provide the structural framework for mounting the 90 Jinko solar modules.

Aluminum rails are suitable for solar applications because they offer:

• Lightweight construction
• Corrosion resistance
• Long service life
• Strong mechanical support
• Easy installation
• Professional finish

The final mounting arrangement will be designed according to the roof or ground installation location, panel orientation, structural requirements and local site conditions.

---

9. 250 A BATTERY FUSE

A:

250 Ampere Battery Fuse

is included as part of the battery protection system.

The battery fuse provides protection against excessive current conditions and helps protect the battery cables, inverter and battery bank from potentially damaging high-current faults.

---

10. THREE-PHASE AUTOMATIC CHANGEOVER SWITCH

The system includes a:

Three-Phase Automatic Changeover Switch

This allows automatic switching between available power sources according to the system configuration.

The changeover arrangement can facilitate switching between:

• Solar/inverter supply
• Grid supply
• Backup supply

This provides continuity of power to the connected loads while helping ensure that the different power sources are properly managed.

---

11. PV DISCONNECT

A dedicated:

PV DC Disconnect

is included to provide a means of isolating the solar PV array from the inverter.

This is important for:

• Maintenance
• Troubleshooting
• Emergency isolation
• Safe servicing
• Solar installation protection

---

12. DC BREAKERS

The system includes:

6 × DC Breakers

These provide additional protection and isolation for the DC side of the solar installation.

They help protect individual circuits and equipment against abnormal current conditions and provide convenient isolation during maintenance.

---

13. LIGHTNING PROTECTION

The system includes:

2 × Lightning Arrestors

Lightning protection is particularly important for solar installations because PV arrays are normally installed on exposed rooftops or structures.

The lightning protection arrangement helps reduce the risk of damage caused by electrical surges associated with lightning and transient overvoltage events.

---

14. PURE COPPER EARTH RODS

The system includes:

2 × Pure Copper Earth Rods

The earthing system provides a low-resistance path for fault and surge currents and forms an important part of the overall electrical safety and lightning-protection system.

Proper earthing will be installed according to applicable electrical standards and site requirements.

---

15. AUTOMATIC THREE-PHASE VOLTAGE REGULATOR

The system comes with an:

Automatic Three-Phase Voltage Regulator

The voltage regulator is designed to help stabilize the incoming electrical supply where grid voltage fluctuations occur.

This is particularly beneficial for installations where sensitive electrical and electronic equipment needs a more stable supply voltage.

It can help protect connected equipment from undesirable voltage variations and improve the overall reliability of the electrical system.

---

16. METALLIC TRUNKING

The installation includes:

2 × 4 × 4 Metallic Trunking

The metallic trunking provides organized routing and mechanical protection for electrical cables.

It helps provide:

• Neat cable management
• Mechanical protection
• Improved installation appearance
• Reduced exposure of cables
• Easier maintenance
• Safer electrical installation

---

17. 16.0 mm² AC SINGLE CABLE

The system includes:

4 Rolls of 16.0 mm² AC Single Cable

These cables are used for suitable AC connections within the system, subject to the final electrical design and installation requirements.

The cable sizing should be verified against the actual cable run length, installation method, current rating, voltage drop and applicable electrical regulations.

---

18. COMPLETE SYSTEM ENERGY FLOW

The system is designed to operate intelligently according to the availability of solar energy, battery charge level and grid supply.

During the Day

Jinko Solar Panels → Felicity Hybrid Inverter → Loads

Solar energy is first used to power the connected loads.

Any available excess solar generation can be directed toward charging the battery bank.

When Solar Generation Exceeds Load Demand

Jinko PV → Inverter → Battery Bank

Excess solar energy is stored in the 102.4 kWh lithium battery bank for later use.

During the Evening/Night

Battery Bank → Felicity Inverter → Loads

The stored battery energy can supply the loads after solar production decreases.

During Grid Failure

Battery → Hybrid Inverter → Loads

The inverter can provide backup power from the battery bank, subject to the inverter’s output capability and the connected load requirements.

When Battery Energy Becomes Low

The system can utilize the available grid supply, depending on the programmed operating mode and installation configuration.

---

19. APPROXIMATE BATTERY BACKUP CAPABILITY

The battery bank has a nominal capacity of:

102.4 kWh

Actual usable energy will depend on the programmed depth of discharge, inverter efficiency, battery operating conditions and other system losses.

For illustration:

*These are theoretical calculations based on nominal 102.4 kWh storage and do not represent guaranteed usable runtime. Actual runtime will be lower depending on reserve SOC, inverter efficiency, battery temperature, discharge limits and load characteristics.

---

20. SYSTEM CAPACITY SUMMARY

Solar Generation

90 × 635 W Jinko Monocrystalline Panels

= 57.15 kWp Solar PV Capacity

Inverter

1 × Felicity IVGM50KHP3G2

= 50 kW / 55 kVA Three-Phase Hybrid Inverter

Battery Storage

20 × 5.12 kWh Felicity Lithium Batteries

= 102.4 kWh Nominal Battery Storage

MPPT Capacity

80 kW

= 20 kW × 4 MPPT

PV Input

150–850 VDC

Battery Voltage

160–800 VDC

---

21. MAJOR ADVANTAGES OF THE 55 kVA / 50 kW FELICITY SOLAR SYSTEM

1. High 50 kW Output Capacity

The 50 kW inverter can support substantial three-phase commercial and industrial loads.

2. 102.4 kWh Battery Storage

The large lithium battery bank provides significant energy storage for nighttime consumption and backup requirements.

3. Hybrid On-Grid and Off-Grid Operation

The system can integrate solar, batteries and grid power to provide flexible energy management.

4. High PV Input Capability

The inverter’s 80 kW MPPT capacity provides significant solar-input flexibility.

5. Three-Phase Power

Ideal for facilities operating three-phase machinery and electrical equipment.

6. High-Voltage Battery Architecture

The 160–800 VDC battery input range allows efficient integration with the high-voltage battery system.

7. Grade A Lithium Battery Technology

The Felicity battery modules provide reliable energy storage with long-term operating capability.

8. Excellent Solar Capacity

The 57.15 kWp Jinko PV array can generate substantial daytime energy to reduce dependence on grid electricity.

9. Energy Cost Reduction

Solar energy can replace a significant portion of electricity purchased from the grid.

10. Backup During Power Outages

Stored battery energy can keep selected or appropriately sized loads operating when grid power fails.

11. Intelligent Energy Management

The hybrid inverter coordinates PV generation, battery storage, grid supply and loads.

12. Professional Protection System

The package incorporates DC breakers, PV disconnect, battery fuse, lightning arrestors, earthing equipment and automatic changeover protection.

13. Voltage Stabilization

The three-phase automatic voltage regulator provides additional protection where grid voltage fluctuations are experienced.

14. Expandable Energy Storage

The battery architecture allows the storage system to be designed around substantial energy requirements.

15. IP65 Inverter Protection

The IP65-rated inverter enclosure provides protection against dust ingress and water jets, making it suitable for appropriately selected indoor or protected outdoor installation environments.

---

22. COMPLETE SYSTEM PACKAGE

The system includes:

• 1 × 55 kVA / 50 kW Felicity IVGM50KHP3G2 Three-Phase Hybrid Inverter
• Built-in 80 kW MPPT – 20 kW × 4
• 8 PV input ports
• Wi-Fi monitoring module
• 1 × FLH48100UCG2 Master Battery Controller
• 20 × FLH48100UMG2 5.12 kWh 48 V 100 Ah Grade A Lithium Batteries
• 2 × FLH48100R13G2 13-layer battery racks
• 90 × 635 W Jinko Monocrystalline Solar PV Modules
• 57.15 kWp total PV capacity
• 1,000 m of 10 mm² solar PV cable
  • 500 m Red
  • 500 m Black
• 32 × 4.8 m Aluminum Long Rails
• 1 × 250 A Battery Fuse
• 1 × Three-Phase Automatic Changeover Switch
• PV Disconnect
• 6 × DC Breakers
• 2 × Lightning Arrestors
• 2 × Pure Copper Earth Rods
• 1 × Automatic Three-Phase Voltage Regulator
• 2 × 4 × 4 Metallic Trunking
• 4 Rolls of 16.0 mm² AC Single Cable
• Complete installation labour

---

23. INSTALLATION AND WARRANTY

FREE PROFESSIONAL INSTALLATION

The system comes with free installation, including professional installation and commissioning of the solar PV system, inverter, battery storage, protection equipment and associated components.

The installation will be carried out according to the system design, site conditions and applicable electrical safety requirements.

WARRANTY

Felicity Hybrid Inverter:
5-Year Warranty

Felicity Lithium Batteries:
10-Year Warranty

The applicable warranty terms, exclusions and conditions should be confirmed against the manufacturer’s warranty documentation at the time of installation.

---

CONCLUSION

The 55 kVA / 50 kW Felicity High-Voltage Three-Phase Solar System is a comprehensive commercial and industrial energy solution combining 57.15 kWp of Jinko solar generation, 102.4 kWh of lithium battery storage and a 50 kW / 55 kVA three-phase hybrid inverter.

Its combination of high solar input capability, substantial battery storage, three-phase output, automatic grid integration, voltage regulation, comprehensive electrical protection and professional installation makes it suitable for businesses and institutions seeking to reduce electricity costs, improve energy independence and maintain reliable power during grid interruptions.

The system is particularly well suited for commercial buildings, offices, schools, hospitals/clinics, farms, hotels, workshops, manufacturing facilities, apartment buildings and other premises with significant three-phase electrical loads.
