6kWh High Frequency Solar System with a 5kWh SRNE Lithium Battery

System Overview

The 6kWh High Frequency SRNE Solar System is a reliable and efficient hybrid solar power solution designed for homes, offices, shops, small businesses and other applications requiring dependable electricity and backup power.

The system combines a 6kWh high-frequency SRNE hybrid inverter, a 5kWh 48V SRNE lithium battery, and 6 pieces of 620W Jinko bifacial monocrystalline solar panels.

The solar panels generate power during the day, supplying the connected loads while also providing energy for charging the lithium battery. The stored battery energy can then be used when solar production is insufficient or when grid power is unavailable.

1. 6kWh High-Frequency SRNE Hybrid Solar Inverter

Specifications

• Brand: SRNE
• Inverter Capacity: 6kWh
• Technology: High Frequency
• Type: Smart Hybrid Solar Inverter
• System: Solar + Battery + Grid
• Connectivity: Wi-Fi compatible
• Warranty: 5 years
• Application: Residential and small commercial solar systems

The SRNE hybrid inverter is the central component of the system. It manages power generated from the solar panels, controls battery charging and supplies electricity to the connected loads.

The high-frequency design provides a compact and efficient power-conversion solution suitable for everyday residential and small commercial applications.

Advantages

• Efficient solar-to-load power conversion
• Compact high-frequency design
• Hybrid operation with solar, battery and grid power
• Supports battery backup operation
• Wi-Fi compatible for convenient monitoring
• Suitable for homes and small businesses
• Helps reduce dependence on grid electricity
• Provides automatic management of available energy sources

The source information identifies the SRNE inverter as a smart hybrid inverter with Wi-Fi compatibility and a 5-year warranty.

2. 5kWh 48V SRNE Lithium Battery

The system is equipped with:

1 × 5kWh 48V SRNE Lithium Battery

The lithium battery stores excess solar energy generated during the day and makes it available for use when solar generation is low or during power interruptions.

Battery Specifications

• Brand: SRNE
• Capacity: 5kWh
• Nominal Voltage: 48V
• Battery Type: Lithium
• Application: Solar energy storage and backup power
• Battery Management: Compatible with battery management/protection systems
• System Configuration: 48V battery storage

Benefits of the Lithium Battery

• Efficient energy storage
• Provides backup power during grid outages
• Stores excess daytime solar energy
• Compact compared with many traditional battery technologies
• Suitable for daily solar charging and discharging
• Helps increase solar energy utilization
• Designed for integration with the SRNE hybrid inverter

Note: The uploaded source originally lists a 10kWh/51.2V SRNE lithium battery with Grade-A cells, built-in BMS, up to 6,000 cycles and a 10-year warranty. Since you have specifically requested a 5kWh 48V SRNE lithium battery, those original battery-specific ratings have not been carried over to the revised specification unless confirmed for the 5kWh/48V model.

3. Solar PV System

The solar array has been adjusted to:

6 × 620W Jinko Bifacial Monocrystalline Solar Panels

Total installed solar capacity:

6 × 620W = 3,720W

Total PV Capacity: 3.72kWp

The Jinko panels are specified as:

• 620W per panel
• Bifacial monocrystalline technology
• 24% transfer efficiency
• All-weather design
• 25-year warranty

The bifacial design can capture useful reflected light from the rear side of the modules when the installation environment and mounting arrangement allow it.

4. How the Solar System Works

During the Day

The 6 Jinko solar panels generate electricity:

3.72kWp Solar Array → SRNE Hybrid Inverter → Connected Loads

The solar power can directly supply the electrical loads. Any available surplus can be used to charge the 5kWh lithium battery.

When Solar Power Is Low

The system can draw energy from the battery:

5kWh Lithium Battery → SRNE Inverter → Connected Loads

This allows stored solar energy to be used during periods of low sunlight.

During a Grid Power Outage

The SRNE inverter can use the stored battery energy to supply supported backup loads, subject to the inverter’s capacity, battery state of charge and the specific loads connected to the backup output.

5. Solar Protection and Electrical Components

The system includes the following supporting components:

• 1 × 8-way combiner box
• 1 × PV disconnect
• 2 × DC double-pole switches
• 1 × surge protector
• 1 × AC double-pole breaker
• 1 × automatic changeover switch
• 1 × digital automatic voltage regulator
• 6.0mm twin-with-earth single cable
• 25mm flexible conduit
• 4 × 2 trunking
• Aluminum long mounting rails

These components provide electrical protection, isolation, cable management and mounting support for the solar installation.

6. Automatic Changeover Switch

The system includes an automatic changeover switch to facilitate automatic switching between available power sources according to the configured system arrangement.

This is particularly useful where continuity of electricity supply is important.

7. Digital Automatic Voltage Regulator

A digital automatic voltage regulator is included to help regulate the applicable incoming electrical supply and provide additional voltage stability for the connected system.

8. Solar Mounting Structure

The system includes standard aluminum long mounting rails.

The aluminum structure is:

• Lightweight
• Non-corrosive
• Suitable for outdoor solar installations
• Designed to securely support the PV modules

The supplied specification identifies the mounting rails as standard non-corrosive aluminium rails.

9. Key Advantages of the Complete System

1. Reliable Solar Power

The 3.72kWp solar array provides renewable daytime energy for the connected loads.

2. Battery Backup

The 5kWh lithium battery stores solar energy for use when solar generation is unavailable or insufficient.

3. High-Frequency Inverter Technology

The high-frequency SRNE inverter provides an efficient and compact solution for solar power conversion.

4. Reduced Grid Dependence

Using solar energy during the day can reduce reliance on electricity from the grid.

5. Smart Hybrid Operation

The system combines solar, battery and grid power into one integrated energy-management solution.

6. Wi-Fi Monitoring

The SRNE inverter is Wi-Fi compatible, allowing convenient monitoring of system operation.

7. Bifacial Solar Technology

The Jinko bifacial panels can utilize suitable rear-side reflected light in addition to direct sunlight, depending on the installation environment.

8. Automatic Power Changeover

The automatic changeover system helps maintain power availability when switching between available sources.

9. Comprehensive Protection

The system includes PV disconnects, DC switches, surge protection, AC protection and a combiner box.

10. Long-Term Solar Investment

The system combines solar generation, lithium energy storage and hybrid inverter technology to provide a long-term renewable energy solution.

10. System Summary

Component	Specification
Hybrid Inverter	6kWh SRNE High-Frequency Smart Hybrid Inverter
Battery	5kWh 48V SRNE Lithium Battery
Solar Panels	6 × 620W Jinko Bifacial Monocrystalline
Total Solar Capacity	3.72kWp
Solar Panel Warranty	25 years
Inverter Warranty	5 years
PV Protection	PV Disconnect + DC Double Pole Switches
Solar Distribution	8-Way Combiner Box
AC Protection	AC Double Pole Breaker
Power Switching	Automatic Changeover Switch
Voltage Protection	Digital Automatic Voltage Regulator
Surge Protection	Surge Protector
Mounting	Aluminum Long Rails
Monitoring	Wi-Fi Compatible

Final System Description

The 6kWh High Frequency Solar System combines a 6kWh High Frequency SRNE Hybrid Inverter, a 5kWh 48V SRNE Lithium Battery, and 6 × 620W Jinko Bifacial Monocrystalline Solar Panels, giving the system a total solar PV capacity of 3.72kWp. It is designed to provide efficient daytime solar power, battery energy storage and backup power while reducing dependence on grid electricity.
